Software Overview

MADRIX® KEY

  • Includes an empty MADRIX® KEY.
  • Requires a proper MADRIX® 5 License / MADRIX® RADAR License to activate the features or output for the MADRIX® 5 Software / MADRIX® RADAR Software.
  • Includes 1x MADRIX® KEY, 1x USB flash drive incl. MADRIX® 5 Software and MADRIX® RADAR Software, 1x lanyard, and 1x quick start guide in a beautiful, high-quality box.

# Order Number Product

01 IA-SW-005007 MADRIX® KEY  Includes 1x empty MADRIX® KEY.

MADRIX® 5 Licenses

  • Require a valid, empty, and metallic MADRIX® KEY.
  • Online activation initially required one time.
  • Only one MADRIX® 5 License is possible per MADRIX® KEY.
  • A MADRIX® 5 License is only valid for MADRIX® 5.

# Order Number Product

01 IA-SW-005036 MADRIX® 5 preprogrammer  Provides no output for MADRIX® 5, but removes major limitations of the demo mode.

02 IA-SW-005008 MADRIX® 5 start  Provides the output license for 2x 512 DMX channels and 64 x 64 DVI voxels for MADRIX® 5.

03 IA-SW-005009 MADRIX® 5 entry Provides the output license for 8x 512 DMX channels and 128 x 128 DVI voxels for MADRIX® 5.

04 IA-SW-005010 MADRIX® 5 basic Provides the output license for 32x 512 DMX channels and 512 x 512 DVI voxels for MADRIX® 5.

05 IA-SW-005011 MADRIX® 5 professional Provides the output license for 128x 512 DMX channels and 1,024 x 1,024 DVI voxels for MADRIX® 5.

06 IA-SW-005012 MADRIX® 5 ultimate Provides the output license for 512x 512 DMX channels and 2,048 x 1,024 DVI voxels for MADRIX® 5.

07 IA-SW-005013 MADRIX® 5 maximum Provides the output license for 2,048x 512 DMX channels and 2,048 x 1,024 DVI voxels for MADRIX® 5.

MADRIX® 5 License Upgrades

  • Upgrade your MADRIX® 5 License on your MADRIX® KEY to a higher license in order to increase the available output.
  • MADRIX® 5 License Upgrades to higher licenses are possible several times per MADRIX® KEY.
  • Online activation initially required one time.
  • Require a valid and metallic MADRIX® KEY with a MADRIX® 5 License.

# Order Number Product

01 IA-SW-005014 MADRIX® 5 start > entry Upgrade from MADRIX® 5 start to MADRIX® 5 entry.

02 IA-SW-005015 MADRIX® 5 start > basic Upgrade from MADRIX® 5 start to MADRIX® 5 basic.

03 IA-SW-005016 MADRIX® 5 start > professional Upgrade from MADRIX® 5 start to MADRIX® 5 professional.

04 IA-SW-005017 MADRIX® 5 start > ultimate Upgrade from MADRIX® 5 start to MADRIX® 5 ultimate.

05 IA-SW-005018 MADRIX® 5 start > maximum Upgrade from MADRIX® 5 start to MADRIX® 5 maximum.

06 IA-SW-005019 MADRIX® 5 entry > basic Upgrade from MADRIX® 5 entry to MADRIX® 5 basic.

07 IA-SW-005020 MADRIX® 5 entry > professional Upgrade from MADRIX® 5 entry to MADRIX® 5 professional.

08 IA-SW-005021 MADRIX® 5 entry > ultimate Upgrade from MADRIX® 5 entry to MADRIX® 5 ultimate.

09 IA-SW-005022 MADRIX® 5 entry > maximum Upgrade from MADRIX® 5 entry to MADRIX® 5 maximum.

10 IA-SW-005023 MADRIX® 5 basic > professional Upgrade from MADRIX® 5 basic to MADRIX® 5 professional.

11 IA-SW-005024 MADRIX® 5 basic > ultimate Upgrade from MADRIX® 5 basic to MADRIX® 5 ultimate.

12 IA-SW-005025 MADRIX® 5 basic > maximum Upgrade from MADRIX® 5 basic to MADRIX® 5 maximum.

13 IA-SW-005026 MADRIX® 5 professional > ultimate Upgrade from MADRIX® 5 professional to MADRIX® 5 ultimate.

14 IA-SW-005027 MADRIX® 5 professional > maximum Upgrade from MADRIX® 5 professional to MADRIX® 5 maximum.

15 IA-SW-005028 MADRIX® 5 ultimate > maximum Upgrade from MADRIX® 5 ultimate to MADRIX® 5 maximum.

MADRIX® 5 Software Updates

  • Take advantage of the latest MADRIX® 5 Software. This will even automatically increase your available output.
  • Online activation initially required one time.
  • Requires a valid and metallic MADRIX® KEY. Any green MADRIX® KEY needs to be disabled and physically replaced, i.e. purchase of 1x MADRIX® KEY required.
  • The MADRIX® 5 Software Update is free of charge if you have bought MADRIX® Software on April 01, 2017 or any later date. Please contact your dealer!
  • This process cannot be reversed. A MADRIX® 5 License is only valid for MADRIX® 5.

# Order Number Product

01 IA-SW-005029 MADRIX® 5 Software Update start Update from start or dvi start (MADRIX® 2 or MADRIX® 3) to MADRIX® 5 start.

02 IA-SW-005030 MADRIX® 5 Software Update entry Update from entry or dvi entry (MADRIX® 2 or MADRIX® 3) to MADRIX® 5 entry.

03 IA-SW-005031 MADRIX® 5 Software Update basic Update from basic or dvi (MADRIX® 2 or MADRIX® 3) to MADRIX® 5 basic.

04 IA-SW-005032 MADRIX® 5 Software Update professional Update from professional (MADRIX® 2 or MADRIX® 3) to MADRIX® 5 professional.

05 IA-SW-005033 MADRIX® 5 Software Update ultimate Update from ultimate (MADRIX® 2 or MADRIX® 3) to MADRIX® 5 ultimate.

MADRIX® RADAR fusion Licenses

  • Require a valid, metallic MADRIX® KEY.
  • Online activation initially required one time.
  • It is possible to have a MADRIX® RADAR fusion license and a MADRIX® RADAR big data license on a single MADRIX® KEY.

# Order Number Product

01 IA-SW-005051 MADRIX® RADAR fusion small Unlocks management, configuration, and monitoring of up to 32 RDM devices/sub-devices for MADRIX® RADAR.

02 IA-SW-005052 MADRIX® RADAR fusion medium Unlocks management, configuration, and monitoring of up to 256 RDM devices/sub-devices for MADRIX® RADAR.

03 IA-SW-005053 MADRIX® RADAR fusion large Unlocks management, configuration, and monitoring of up to 2,048 RDM devices/sub-devices for MADRIX® RADAR.

MADRIX® RADAR fusion License Upgrades

  • Upgrade your MADRIX® RADAR fusion license on your MADRIX® KEY to a higher license in order to unlock more RDM devices/sub-devices.
  • Online activation initially required one time.
  • Require a valid and metallic MADRIX® KEY with a MADRIX® RADAR fusion license.

# Order Number Product

01 IA-SW-005054 MADRIX® RADAR fusion small > fusion medium Upgrade from MADRIX® RADAR fusion small to MADRIX® RADAR fusion medium.

02 IA-SW-005055 MADRIX® RADAR fusion small > fusion large Upgrade from MADRIX® RADAR fusion medium to MADRIX® RADAR fusion large.

03 IA-SW-005056 MADRIX® RADAR fusion medium > fusion large Upgrade from MADRIX® RADAR fusion medium to MADRIX® RADAR fusion large.

MADRIX® RADAR big data Yearly Licenses

  • Require a valid, metallic MADRIX® KEY.
  • Online activation initially required one time.
  • It is possible to have a MADRIX® RADAR fusion license and a MADRIX® RADAR big data license on a single MADRIX® KEY.

# Order Number Product

01 IA-SW-005050 MADRIX® RADAR big data Unlocks the Big Data features for 1 year for MADRIX® RADAR.





Hardware Overview

# Order Number Product

01 IA-HW-001029 MADRIX® AURA 2 Stand-Alone Recorder/Player, 2 Universes Over Network, DIN Rail

02 IA-HW-001025 MADRIX® AURA 8 Stand-Alone Recorder/Player, 8 Universes Over Network, DIN Rail

03 IA-HW-001026 MADRIX® AURA 32 Stand-Alone Recorder/Player, 32 Universes Over Network, DIN Rail

04 IA-HW-001014 MADRIX® LUNA 4 Network Node / USB 2.0 DMX512 Interface, 4x DMX-OUT, 1x DMX-IN, 19", Power Cord: EU Or US

05 IA-HW-001008 MADRIX® LUNA 8 Network Node / USB 2.0 DMX512 Interface, 8x DMX-OUT, 1x DMX-IN, 19", Power Cord: EU Or US

06 IA-HW-001015 MADRIX® LUNA 16 Network Node / USB 2.0 DMX512 Interface, 16x DMX-OUT, 1x DMX-IN, 19", Power Cord: EU Or US

07 IA-HW-001019 MADRIX® STELLA Network Node / USB 2.0 DMX512 Interface, 2x DMX-IN/OUT, RDM, DIN Rail

08 IA-HW-001018 MADRIX® NEBULA Network Node / USB 2.0 Interface, SPI Converter For 8 Universes, 2x OUT, DIN Rail

09 IA-HW-001021 MADRIX® ORION Network Node, 8x Analog Inputs, DIN Rail

10 IA-HW-001001 MADRIX® USB ONE USB 2.0 DMX512 Interface, 1x DMX-IN/OUT

11 IA-HW-001016 MADRIX® USB SMPTE USB 2.0 Plug-And-Play Input Unit, 1x 3-Pin XLR Input

12 IA-HW-001002 XLR Gender Changer 5-Pin Male To 5-Pin Male

13 IA-HW-001006 XLR Adapter Silver 5-Pin Male To 3-Pin Female

14 IA-HW-001020 XLR Adapter Black (Premium Quality)  5-Pin Male To 3-Pin Female

15 IA-HW-001024 MADRIX® STELLA Accessory Replacement Set Set Of Screw Terminals (2x 3-pin and 1x 2-pin) And 2x Wall-Mount Brackets

16 IA-HW-001023 MADRIX® NEBULA Accessory Replacement Set Set Of Screw Terminals (2x 4-pin and 1x 2-pin) And 2x Wall-Mount Brackets

17 IA-HW-001022 MADRIX® ORION Accessory Replacement Set Set Of Screw Terminals (2x 6-pin and 1x 2-pin) And 2x Wall-Mount Brackets

18 IA-HW-001027 DIN-Rail Power Supply 12 V MEAN WELL, DC Output: 12 V, 1.25 A, 15 W, 1 SU, DIN Rail

19 IA-HW-001028 Plug-In Power Supply 3 V - 12 V DC Output: 3 V / 4.5 V / 5 V / 6 V / 7.5 V / 9 V / 12 V, 2.0 A max.





Important Information

  • For pricing information, please contact your local dealer.
